Inductive Sensor For the food industry

NI12U-EM18WD-AN6X-H1141/S1163

Order ID no. 1645353

Ambient temperature max. (°C): 100
Ambient temperature min. (°C): -40
Connector type: M12 x 1
Design: Threaded barrel
Electrical connection: Connector
Housing diameter (mm): ⌀ 18 mm
Housing material: Stainless steel
Housing quality: 1.4404 (AISI 316L)
Mounting conditions: Non-flush
Operating voltage: DC
Output function: NPN
Protection class: IP68, IP69K
Quality active face: LCP
Rated switching distance (mm): 12
Special features: Factor 1, Pressure resistant, Resistant to magnetic fields, Sn +, uprox+, Wash down
Switching element function: normally open NO
Switching frequency (kHz): 1
