Inductive Sensor For the food industry

NI15U-EM18WDTC-AP6X

Order ID no. 1634763

Ambient temperature max. (°C): 100
Ambient temperature min. (°C): -40
Connector type: Removable cage clamp terminals
Design: Threaded barrel
Electrical connection: Terminal chamber
Housing diameter: ⌀ 18 mm
Housing material: Stainless steel
Housing quality: 1.4404 (AISI 316L)
Mounting conditions: Non-flush
Operating voltage: DC
Protection class: IP68, IP69K
Quality active face: LCP
Rated switching distance (mm): 15
Special features: Factor 1, Pressure resistant, Resistant to magnetic fields, Sn +, uprox+, Wash down
Switching element function: normally open NO
Switching frequency (kHz): 1
