Accessories for Fieldbus Systems
EC-FKDW4.54-0.5/16
Order ID no. 6935753
In Stock
Price Group
K1
List Price
€14.60
home
Turck-Shop
Products
Connectivity
Receptacles
EC-FKDW4.54-0.5/16
Technical Data
Downloads
Network protocol
PROFIBUS-DP
Application
Data
Connector A
Female, M12 × 1, Straight, B-coded
Number of pins
5
Receptacle housing material A
Brass
Screw-in thread
M16 × 1.5
Voltage (V)
60
Current (A)
4
Approvals
CE
Core cross-section (mm²)
0.34
Connection mode
Wire connection
Number of Conductors
5
Conductor length (m)
0.5
Device type
Receptacle
Key Features
Connector A
Female, M12 × 1, Straight, B-coded
Number of pins
5
Receptacle housing material A
Brass
Screw-in thread
M16 × 1.5
