- Ambient temperature max. (°C)
- 60
- Ambient temperature min. (°C)
- -25
- Approvals
- cULus, CE, UKCA
- Connection technology signal
- M12
- Dimensions (L x W x H)
- 232,4 mm x 62,4 mm x 35,3 mm
- Network protocol
- Modbus TCP, EtherNet/IP, PROFINET, CC-Link IE Field Basic
- Fieldbus connection technology
- 2 x M12, 4-pin, D-coded
- Fieldbus transmission rate
- 10/100 Mbps
- Output voltage
- 24 VDC from potential group
- Voltage supply connection
- 1 × M12, A-coded
- Product type
- I/O Module, Compact station
- Protection class
- IP67
- Signal type
- IO-Link, Digital output, Digital input/output, Digital input
