PT600R-2113-I2-AMPS1.5

Order ID no. 100003594

Ambient temperature max. (°C): 100
Ambient temperature min. (°C): -40
Connector type: AMP Superseal 1.5
Design: Without display
Electrical output: Current output (2-wire)
Electrical connection: Connector
Housing material: Stainless-steel/Plastic
Housing quality: 1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
Material pressure transducer: Stainless steel 1.4404 (AISI 316L)
Media temperature max. (°C): 125
Media temperature min. (°C): -40
Operating voltage: DC
Output function: Analog output current
Pressure range: 0...600 bar
Pressure type: Relative pressure
Process connection: G 1/8″ male thread (back sealing) according to DIN EN ISO 1179-2 with FPM profile sealing ring
Protection class: IP67
