BSc, March 12, 2020:

PT600R-2113-I2-DT043P

Order ID no. 100003595

Ambient temperature max. (°C): 100
Ambient temperature min. (°C): -40
Connector type: Deutsch DT04-3P
Design: Without display
Electrical output: Current output (2-wire)
Electrical connection: Connector
Housing material: Stainless-steel/Plastic
Housing quality: 1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
Material pressure transducer: Stainless steel 1.4404 (AISI 316L)
Media temperature max. (°C): 125
Media temperature min. (°C): -40
Operating voltage: DC
Output function: Analog output current
Pressure range: 0...600 bar
Pressure type: Relative pressure
Process connection: G 1/8″ male thread (back sealing) according to DIN EN ISO 1179-2 with FPM profile sealing ring
Protection class: IP69K
