Absolute Rotary Encoder - Multiturn

REM-106B12E-9D32B-B1M12/N46

Order ID no. 100011430

In Stock
Price Group	F3
List Price	€638.00

Item Total€638.00

Quantity

Contact Support

homeTurck-Shop
Products
Sensors
Encoders
REM-106B12E-9D32B-B1M12/N46

Protection class: IP67
Communication protocol: CANopen
Electrical connection: Connector
Connector type: M12 × 1
Housing material: Die-cast zinc
Ambient temperature min. (°C): -40
Ambient temperature max. (°C): 80
Measuring principle: Optical
Output type: Absolute multiturn
Shaft Type: Blind hole shaft
Shaft diameter D (mm): 12 mm
Flange diameter (mm): 63
Flange type: Flange with stator coupling
Design: Hollow shaft
Encoder line: Industrial-Line
Technology: Optical
Protection class shaft: IP67

Key Features

Output type: Absolute multiturn
Flange diameter (mm): 63
Shaft diameter D (mm): 12
Shaft Type: Blind hole shaft
