RS-31H12E-3C13B-12M23 | TURCK - Your Global Automation Partner

Absolute Rotary Encoder - Singleturn

RS-31H12E-3C13B-12M23

Order ID no. 1544423

homeHome
Loading...

Ambient temperature max. (°C): 70
Ambient temperature min. (°C): -40
Communication protocol: SSi
Design: Hollow shaft
Electrical connection: Connector
Encoder line: Industrial-Line
Flange diameter (mm): 63
Flange type: Flange with stator coupling
Housing material: Die-cast zinc
Measuring principle: Optical
Output type: Absolute singleturn
Protection class: IP67
Protection class shaft: IP67
Shaft diameter D (mm): 12 mm
Shaft Type: Blind hole shaft
Special features: Standard
Technology: Optical

homeTurck-Shop
Products
Sensors
Encoders
RS-31H12E-3C13B-12M23

Key Features

Output type: Absolute singleturn
Flange diameter (mm): 63
Shaft diameter D (mm): 12 mm
Shaft Type: Blind hole shaft

In Stock
Price Group	F3
List Price	731,00 €

Item Total731,00 €
