Inductive Sensor
BI2-EM12WDTC-Y1X
Order ID no. 4012051
In Stock
Price Group
E1
List Price
€97.70
Item Total
€97.70
Quantity
−
+
add_shopping_cart
Add to Cart
Contact Support
home
Turck-Shop
Products
Sensors
Inductive Sensors
BI2-EM12WDTC-Y1X
Technical Data
Downloads
Special features
Wash down, Pressure resistant
Ambient temperature max. (°C)
100
Ambient temperature min. (°C)
-40
Electrical connection
Terminal chamber
Connector type
Removable cage clamp terminals
Design
Threaded barrel
Housing material
Stainless steel
Housing quality
1.4404 (AISI 316L)
Mounting conditions
Flush
Operating voltage
DC
Output function
NAMUR
Protection class
IP68, IP69K
Quality active face
LCP
Rated switching distance (mm)
2
Switching frequency (kHz)
5
Key Features
Electrical connection
Terminal chamber
Mounting conditions
Flush
Output function
NAMUR
Rated switching distance (mm)
2
