Measuring light screen
MAE7216Q
Order ID no. 3072507
home
Home
Loading...
Technical Data
Downloads
Protection class
IP65
Cable length (m)
0.15
Approvals
CE, cULus recognized
Design
Rectangular
Electrical connection
Cable with connector
Connector type
M12 × 1
Housing material
Metal
Housing quality
AL
Ambient temperature min. (°C)
-40
Ambient temperature max. (°C)
70
Max. range (mm)
13500
Function
Light screen
Scan field (mm)
1819
Optical resolution (mm)
9.5
Light type
IR
Number of beams
96
Dimensions
38,1 mm x 38,1 mm x 1908 mm
Operating mode
Emitter
Key Features
Light type
IR
Function
Light screen
Max. range (mm)
13500
In Stock
Price Group
F3
List Price
€1,295.00
