PT10R-2045-I2-CM2.0 | TURCK - Your Global Automation Partner
Pressure Transmitter
PT10R-2045-I2-CM2.0
Order ID no. 100000058
home
Home
Loading...
Technical Data
Downloads
Electrical output
Current output (2-wire)
Ambient temperature max. (°C)
85
Ambient temperature min. (°C)
-30
Approvals
cULus
Electrical connection
Cable
Connector type
Open end
Design
Without display
Housing material
Stainless-steel/Plastic
Housing quality
1.4305 (AISI 303)/polyarylamide 50% GF UL 94 V-0
Material pressure transducer
Stainless steel 1.4016 (AISI 430)
Process connection
7/16″-20 UNF female thread (Schrader)
Media temperature max. (°C)
135
Media temperature min. (°C)
-40
Pressure range
0...10 bar
Operating voltage
DC
Output function
Analog output current
Pressure type
Relative pressure
Protection class
IP67
Key Features
Electrical output
Current output (2-wire)
Process connection
7/16″-20 UNF female thread (Schrader)
In Stock
Price Group
J1
List Price
€130.50
