Differential Pressure Sensor

PS250D-501T-LI2UPN8X-H1141

Order ID no. 100001261

Item Total€835.00

Quantity

Protection class: IP67
Switching element function: NO/NC
Output function: PNP/NPN
Design: With display
Process connection: G 1/4'' female thread
Communication protocol: IO-Link
Electrical connection: Connector
Connector type: M12 × 1
Housing material: Stainless-steel/Plastic
Housing quality: 1.4305 (AISI 303)
Media temperature min. (°C): -40
Media temperature max. (°C): 85
Ambient temperature min. (°C): -40
Ambient temperature max. (°C): 80
Operating voltage: DC
Electrical output: 2 × switching output
Pressure type: Differential Pressure
Material pressure transducer: Ceramic Al₂O₃
Pressure range: 0…250 bar
Display: 4-digit 7-segment display, rotatable by 180°, with switch-off function
