PT100PSIG-1103-I2-H1143 | TURCK - Your Global Automation Partner

Pressure Transmitter

PT100PSIG-1103-I2-H1143

Order ID no. 100004796

homeHome
Loading...

Electrical output: Current output (2-wire)
Ambient temperature max. (°C): 100
Ambient temperature min. (°C): -40
Approvals: CE, cULus
Electrical connection: Connector
Connector type: M12 x 1
Design: Without display
Housing material: Stainless-steel/Plastic
Housing quality: 1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
Material pressure transducer: Ceramic Al₂O₃
Process connection: 1/4″ NPT-18 male thread
Media temperature max. (°C): 125
Media temperature min. (°C): -40
Pressure range: 0...6,89 bar
Operating voltage: DC
Output function: Analog output current
Pressure type: Relative pressure
Protection class: IP69K

Key Features

Electrical output: Current output (2-wire)
Process connection: 1/4″ NPT-18 male thread

In Stock
Price Group	J1
List Price	€138.10
