PT250R-2003-U2-DC91 | TURCK - Your Global Automation Partner
Pressure Transmitter
PT250R-2003-U2-DC91
Order ID no. 100007955
home
Home
Loading...
Technical Data
Downloads
Electrical output
Voltage output (3-wire)
Ambient temperature max. (°C)
85
Ambient temperature min. (°C)
-30
Approvals
cULus
Electrical connection
Connector
Connector type
DIN EN 175301-803 Form C
Design
Without display
Housing material
Stainless-steel/Plastic
Housing quality
1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
Material pressure transducer
Stainless steel 1.4435 (AISI 316L)
Process connection
1/4″ NPT-18 male thread
Media temperature max. (°C)
135
Media temperature min. (°C)
-40
Pressure range
0...250 bar
Operating voltage
DC
Output function
Analog output voltage
Pressure type
Relative pressure
Protection class
IP65
Key Features
Electrical output
Voltage output (3-wire)
Process connection
1/4″ NPT-18 male thread
In Stock
Price Group
J1
List Price
€130.50
