PT10R-1040-U1-H1143 | TURCK - Your Global Automation Partner
Pressure Transmitter
PT10R-1040-U1-H1143
Order ID no. 100048383
home
Home
Loading...
Technical Data
Downloads
Electrical output
Voltage output (3-wire)
Ambient temperature max. (°C)
85
Ambient temperature min. (°C)
-30
Approvals
cULus
Electrical connection
Connector
Connector type
M12 x 1
Design
Without display
Housing material
Stainless-steel/Plastic
Housing quality
1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
Material pressure transducer
Ceramic Al₂O₃
Process connection
G 1/4'' male thread (manometer)
Media temperature max. (°C)
125
Media temperature min. (°C)
-40
Pressure range
0...10 bar
Operating voltage
DC
Output function
Analog output voltage
Pressure type
Relative pressure
Protection class
IP67
Key Features
Electrical output
Voltage output (3-wire)
Process connection
G 1/4'' male thread (manometer)
In Stock
Price Group
J1
List Price
€130.50
