- Protection class
- IP66
- Switching element function
- NO/NC programmable
- Output function
- PNP/NPN
- Approvals
- cULus
- Design
- With display (integrated probe)
- Process connection
- G 1/2″ male thread
- Immersion depth L (mm)
- 16
- Detection type
- medium contact
- Communication protocol
- IO-Link
- Electrical connection
- Connector
- Connector type
- M12 × 1
- Housing material
- Stainless-steel/Plastic
- Housing quality
- 1.4404 (AISI 316L)/Grilamid TR90 UV/Elastollan C 65 A 15 HPM 000/Ultramid A3X2G5
- Ambient temperature min. (°C)
- -40
- Ambient temperature max. (°C)
- 80
- Operating voltage
- DC
- Measuring range
- -50…150 °C
- Electrical output
- 2 × switching output, IO-Link
- Dimensions
- 128,4 mm x 38 mm x 50,2 mm
- Display
- 4-digit 12-segment display, rotatable by 180°, red or green
- Materials (contact with media)
- Stainless steel 1.4404 (AISI 316L), FKM O-ring, AFM flat seal
