TTMS-206A-CF-LIUPN-H1140-L050 | TURCK - Your Global Automation Partner
Temperature Detection
TTMS-206A-CF-LIUPN-H1140-L050
Order ID no. 100006167
home
Home
Loading...
Technical Data
Downloads
Detection type
medium contact
Electrical output
Current output (2-wire), Switching output
Ambient temperature max. (°C)
80
Ambient temperature min. (°C)
-40
Communication protocol
IO-Link
Electrical connection
Connector
Connector type
M12 x 1
Design
Without display (integrated probe)
Housing material
Stainless steel
Housing quality
1.4404 (AISI 316L)
Immersion depth L (mm)
50
Process connection
For compression fittings, thermowell or direct mounting
Mounting conditions
Immersion sensor
Measuring range
-50...350 °C
Operating voltage
DC
Output function
PNP/NPN
Protection class
IP67
Switching element function
NO/NC programmable
Key Features
Communication protocol
IO-Link
Electrical output
Current output (2-wire), Switching output
Process connection
For compression fittings, thermowell or direct mounting
In Stock
Price Group
D2
List Price
€158.00
