Temperature Detection
TP-103A-G1/8-H1141-L024
Order ID no. 9910401
In Stock
Price Group
D2
List Price
€53.80
Item Total
€53.80
Quantity
−
+
add_shopping_cart
Add to Cart
Contact Support
home
Turck-Shop
Products
Sensors
Temperature Sensors
TP-103A-G1/8-H1141-L024
Technical Data
Downloads
Detection type
medium contact
Electrical output
Resistance
Ambient temperature max. (°C)
120
Ambient temperature min. (°C)
-40
Approvals
cULus
Electrical connection
Connector
Connector type
M12 x 1
Design
Temperature probe
Housing material
Stainless steel
Housing quality
1.4404 (AISI 316L)
Immersion depth L (mm)
24
Process connection
G 1/8'' male thread
Mounting conditions
Immersion sensor
Measuring range
-50...120 °C
Protection class
IP67
Key Features
Electrical output
Resistance
Process connection
G 1/8'' male thread
