Flow Meter

FP100-300L-04-NA-H1141

Order ID no. 100001045

Protection class: IP66
Approvals: CE, cULus
Design: Without display (integrated probe)
Immersion depth L (mm): 16.9
Medium: liquids
Electrical connection: Connector
Connector type: M12 × 1
Housing material: Stainless steel
Housing quality: 1.4571 (AISI 316Ti)
Media temperature min. (°C): -25
Media temperature max. (°C): 85
Ambient temperature min. (°C): -40
Ambient temperature max. (°C): 80
Mounting conditions: Immersion sensor
Function: Flow monitoring
Materials (contact with media): Stainless steel 1.4571 (AISI 316Ti), FKM O-ring, AFM flat seal
Bar length (mm): 45
