Flow Monitoring
FCI-D03A4-NA-H1141/M12
Order ID no. 6870635
In Stock
Price Group
D2
List Price
€328.20
Item Total
€328.20
Quantity
−
+
add_shopping_cart
Add to Cart
Contact Support
home
Turck-Shop
Products
Sensors
Flow Sensors/Flow Meters
FCI-D03A4-NA-H1141/M12
Technical Data
Downloads
Protection class
IP67
Design
Inline
Process connection
M12 × 1.5
Medium
liquids
Detection type
Calorimetric
Electrical connection
Connector
Connector type
M12 × 1
Housing material
Stainless steel
Housing quality
1.4571 (AISI 316Ti)
Media temperature min. (°C)
-20
Media temperature max. (°C)
80
Ambient temperature min. (°C)
-20
Ambient temperature max. (°C)
70
Mounting conditions
Inline sensor
Function
Flow monitoring
Application area
Standard
Dimensions
121,1 mm x 38 mm x 49 mm
Display
4-digit 12-segment display, rotatable by 180°, red or green
Key Features
Process connection
M12 × 1.5
