DR30N-M30E-2UPN8X2-H1141 | TURCK - Your Global Automation Partner
arrow_back_ios
arrow_forward_ios
Radar Sensor
DR30N-M30E-2UPN8X2-H1141
Order ID no. 100030153
home
Home
Loading...
Technical Data
Downloads
Ambient temperature max. (°C)
65
Ambient temperature min. (°C)
-25
Beam angle
5°
Communication protocol
IO-Link
Cone angle (°)
5
Connector type
M12 x 1
Design
Threaded barrel
Detection type
contactless
Dimensions (L x W x H)
113,9 mm
Electrical connection
Connector
Frequency range
122 - 123 GHz
Function
Distance measurement
Function
Radar scanner
Housing material
Stainless steel
Housing quality
1.4401 (AISI 316), PTFE
Max. range (mm)
30000
Measuring principle
Radar
Operating voltage
DC
Output function
PNP/NPN
Protection class
IP67, IP69K
Resolution
1 cm
Switching element function
NO/NC programmable
Key Features
Electrical connection
Connector
Output function
PNP/NPN
Beam angle
5°
Max. range (mm)
30000
In Stock
Price Group
G1
List Price
619,00 €
